通用型號 | 機組功率 | 發動機 | 機組尺寸 | 機組重量 KG | ||||||
備用 kw | 主用 KW | 型 號 | 燃油消耗 (l/h) | 汽缸數 | 排氣量 L | 長 | 寬 | 高 | ||
GE18 | 18 | 16 | GEP-AA | 5.33 | 2L | 2.19 | 1600 | 800 | 900 | 463 |
GE30 | 30 | 27 | GEP-DAB | 9.4 | 2L | 2.49 | 1600 | 800 | 900 | 542 |
GE55 | 55 | 50 | GEP-DTA | 12.7 | 4L | 4.21 | 1800 | 790 | 1240 | 840 |
GE90 | 90 | 80 | GEP-DTC | 24.2 | 6L | 6.87 | 2200 | 790 | 1240 | 1279 |
GE100 | 120 | 110 | GEP-DTB | 26.8 | 6L | 6.87 | 2200 | 790 | 1240 | 1312 |
GE137 | 137 | 125 | GEP-DG | 32.2 | 6L | 7.25 | 2750 | 850 | 1350 | 1700 |
GE165 | 165 | 150 | GEP-D5 | 37.9 | 6L | 7.8 | 2860 | 950 | 1350 | 1736 |
GE200 | 200 | 180 | GEP-PA | 44.5 | 6L | 9.83 | 2860 | 950 | 1350 | 1800 |
GE220 | 220 | 200 | GEP-PC | 60 | 6L | 14.2 | 3000 | 1000 | 1350 | 2416 |
GE275 | 275 | 250 | GEP-PT | 70 | 6L | 14.2 | 3200 | 1000 | 1350 | 2478 |
GE310 | 310 | 280 | GEP-MB | 75 | 6L | 14.2 | 3200 | 1000 | 1350 | 2568 |
GE330 | 330 | 300 | GEP-KA | 82 | 6L | 14.2 | 3200 | 1120 | 1350 | 2644 |
GE360 | 360 | 320 | GEP-KA | 95 | 6L | 14.2 | 3200 | 1120 | 1350 | 2648 |
GE400 | 400 | 360 | GEP-KN | 97 | 6L | 19 | 3400 | 1120 | 1560 | 3280 |
GE440 | 440 | 400 | GEP-KP | 105 | 6L | 19 | 3400 | 1120 | 1560 | 3394 |
GE500 | 500 | 450 | GEP-KNQ | 110 | 6L | 19 | 3700 | 1120 | 1560 | 3584 |
GE550 | 550 | 500 | GEP-G | 130 | 6L | 19 | 3700 | 1120 | 1560 | 3617 |
GE600B | 600 | 550 | GEP-G4 | 145 | 12V | 25 | 3670 | 1400 | 1995 | 3880 |
GE670B | 670 | 600 | GEP-G5 | 150 | 12V | 31 | 3670 | 1610 | 1995 | 3950 |
GE720B | 720 | 650 | GEP-GA | 178 | 12V | 33 | 3670 | 1631 | 2010 | 3990 |
GE880B | 880 | 800 | GEP-GN1 | 198 | 12V | 40 | 3750 | 1631 | 1950 | 4170 |
GE670B | 670 | 600 | GEP-G5C | 160 | 12V | 38 | 4500 | 1250 | 1610 | 6164 |
GE720 | 720 | 640 | GEP-GAC | 175 | 12V | 38 | 4500 | 1250 | 1610 | 6371 |
GE800 | 800 | 720 | GEP-G2BC | 190 | 12V | 38 | 4500 | 1250 | 1610 | 6443 |
GE880 | 880 | 800 | GEP-GN1C | 205 | 12V | 40 | 4650 | 1250 | 1610 | 6685 |
GE1000 | 1000 | 900 | GEP-GL | 220 | 12V | 40 | 4700 | 1500 | 1610 | 7811 |
GE1100 | 1100 | 1000 | GEP-GM | 280 | 12V | 51 | 5500 | 1600 | 1610 | 8565 |
GE1300 | 1300 | 1100 | GEP-GN | 290 | 12V | 51 | 5500 | 1600 | 1610 | 9505 |
GE1122S | 1122 | 1020 | GEP-GMS | 270 | 12V | 50 | 4638 | 1790 | 2495 | 9800 |
GE1232S | 1232 | 1120 | GEP-NS | 316 | 12V | 51 | 4580 | 2085 | 2530 | 9800 |
GE1320S | 1320 | 1200 | GEP-GWS | 337 | 12V | 52 | 4900 | 2190 | 3090 | 10500 |
GE1520S | 1520 | 1380 | GEP-NBS | 353 | 16V | 66 | 5330 | 2180 | 2565 | 12000 |
GE1672S | 1672 | 1520 | GEP-NCS | 374 | 16V | 66 | 5440 | 2170 | 2565 | 13600 |
GE1800S | 1800 | 1640 | GEP-PS | 402 | 16V | 66 | 5570 | 2395 | 3390 | 14700 |
GE1980S | 1980 | 1800 | GEP-PCS | 420 | 16V | 80 | 5980 | 2200 | 2555 | 18600 |
GE2328M | 2328 | 2118 | GEP-PBM | 506 | 20V | 95.4 | 5500 | 1620 | 2600 | 15890 |
GE2578M | 2578 | 2330 | GEP-P2MM | 551 | 20V | 95.4 | 5600 | 1620 | 2600 | 16400 |
GE2750M | 3438 | 2750 | GEP-PTM | 590 | 20V | 95.4 | 5700 | 1620 | 2600 | 16910 |
